Acoustic Desk Screen System – Type 2

Dimensions

Available in two thicknesses 12mm and 24mm

Desk screens fit onto 1200mm, 1400mm & 1600mm desks

With the screen returning 600 mm back onto the desk

Desk screen height options are 400mm & 600 mm height

Density

12mm 2,0kg/m²

24mm 3,5kg/m²

Materials

100% Polyester Fiber (PET) 65% recycled material

Installation system

Dimensions

Available in two thicknesses 12mm and 24mm

Desk screens fit onto 1200mm, 1400mm & 1600mm desks

With the screen returning 600 mm back onto the desk

Desk screen height options are 400mm & 600 mm height

Density

12mm 2,0kg/m²

24mm 3,5kg/m²

Materials

100% Polyester Fiber (PET) 65% recycled material

Installation system

Acoustic resistance

12mm – 0.45, 0.80

24mm – 0.75, 0.95

Thermal Resistance

RO.82 (@15°)

VOC Concentration

0.009 mg/m3 (7 days)

Water vapor absorption

ASTM C1104 / C1104-13a Test conditions: 49°C, 95%RH Water vapor absorbed and adsorbed after 4 days: 0.4% by weigh

Impact resistance

ISO 7892:1988

Colour fastness

ISO 105-X12:2016

Dry rating: 4-5 (Highest = 5)

Wet rating: 4-5 (Highest = 5)

Europe and UK: EN13501-1: 2007

24mm

Class C NRC 0.75 Direct Fix Class B NRC 0.75 50mm Air Gap

Variations in fibre mix and colours may occur. All products will be supplied within commercial tolerances.

• Commercial Offices
• Meeting Rooms
• Studios
• Banks
• Libraries
